Technical Data
• Reads 134.2 kHz transponders: HDX and FDX B ISO 11784/5
• 512 Kbytes of memory for animal database and application program
• Real-time clock for logging time/date stamp
• USB 2.0 interface standard (Bluetooth optional)
• Compatible with Windows 95, 98, 2000, XP, and Vista
• 2000 mAh capacity battery, sufficient for over a day's reading
• Audible beep and visual light when the transponder is read
• Clear LCD display
• Large memory capable of storing 1000's of animals with additional information
• One-year warranty
• Robust casing
• Charge via AC power adaptor
• Used in processing areas
• Water Resistant
• FCC, CE Approved, CCIA Listed
Available Models: (Reader without antenna: T4A96)
1. Short loop antenna (23.5 cm, 9 1/4") T4A81
2. Long loop antenna (60 cm, 23 5/8") T4A97
3. Short antenna (8.5 cm, 3 3/8") T4A98
RFID
• 134.2 kHz
• Reads HDX and FDX-B transponder according to ISO 11784/11785
• Synchronizes to stationary readers according to ISO 11785 clause 6
• Advanced Digital Decoding technology (ADD)
Read range
13-18 cm for FDX-B with short loop antenna
18-20 cm for HDX with short loop antenna
33-40 cm for FDX-B with long loop antenna
28-46 cm for HDX with long loop antenna
Limited dynamic reading with Panel antenna
Housing - Long loop / Short loop antenna
Dimensions - 83x12x5cm / 32.5x10x5cm
Weight - 775 gr. / 550 gr.
Battery - 2000 mAh capacity, sufficient for 1 day reading
Dust and water - IP 65
On-board computer
Non-volatile, 512 Kbytes for animal database and application program
Real-time clock for logging time/date stamp
Uploadable application program
PC Interface
USB 2.0 (standard)
Supplied with basic PC program to exchange data between PC and HHR 3000 Pro
Works with Windows 98, 2000, XP, Vista, Windows 7
Optional Bluetooth (1.2) interface
Approvals and certifications
FCC: complies with Part 15 of the FCC rules
EU-JRC: certificate 161/07*
CE: meets EN50082-1 and EN50022
*valid for V1; V2 expected soon
